MILET

  • Technical Specifications
  • Body
    Anodized Aluminium profile with polyamid 66 side covers
  • Gaskets
    Silicone
  • Diffusers
    4 mm Tempered Glass
  • Screws
    Stainless Steel
  • Glands
    2 cable Gland for 5-8 mm Ø cable
  • Mounting Brackets
    Polyamide 66 (Stainless Steel on request)
The Milet series consists of a range of LED and fluorescent sources to deliver the desired light effect to facades, columns, bridges, monuments, and signs. The series is made of an anodized extrusion aluminium body with polyamid side covers. Polyamid brackets are used to mount the fixtures. Stainless steel brackets are also available to increase the distance from the mounting surface if necessary. The fixtures come with integrated electronic ballasts and LEDs used come in 3 different tones of white, as well as blue, red, green, amber and RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

PRODUCT LIST & DOWNLOAD

  • Compare
    290101
    • Diffusers
      Polycarbonate
    • Power - Current
      320 mA (11 W) LED
    • Color
      3000 K
    • Lens
      40°
    • Lumen
      92 lm
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
  • Compare
    290201
    • Diffusers
      Polycarbonate
    • Power - Current
      Halogen 240V 40W
    • Color
      3000 K
    • Lens
      40°
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
    • Lampholder
      G9
  • Compare
    290211
    • Diffusers
      Polycarbonate
    • Power - Current
      Halogen 240V 40W
    • Color
      3000 K
    • Lens
      40°
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
    • Lampholder
      G9
  • Compare
    310111
    • Diffusers
      Clear Glass
    • Power - Current
      Halogen 240V 25-40W
    • Color
      3000 K
    • Lens
      40°
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
    • Lampholder
      G9
  • Compare
    311111
    • Diffusers
      Clear Glass
    • Power - Current
      Halogen 240V 25-40W
    • Color
      3000 K
    • Lens
      40°
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
    • Lampholder
      G9
  • Compare
    312111
    • Diffusers
      Clear Glass
    • Power - Current
      Halogen 240V 40W
    • Color
      3000 K
    • Lens
      40°
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
    • Lampholder
      G9
  • Compare
    314111
    • Diffusers
      Frosted Glass
    • Power - Current
      Halogen 240V 25-40W
    • Color
      3000 K
    • Lens
      40°
    • Voltage
      240V AC with integrated driver (24V AC or DC on request)
    • Cable
      Potted 5 m 3x0,75 H03 VV-F
    • Lampholder
      G9
