PINARA 1 - Downlights

  • Technical Specifications
  • Body
    Polycarbonate
  • Diffusers
    With clear or frosted tempered glass, without glass
  • Gear
    240 V Non-Dimmable Driver (1-10V Dimmable Driver and DALI Driver available on request)
  • Cable
    0.5 m 2 x 0,75 mm H03 VV-F
  • LED
    350 - 500 - 700 mA (Nichia)
  • Springs
    Steel
  • Heatsing
    Aluminium extrusion profile
The PINARA LED downlight is specially designed to deliver high output LED light with very clean beam angles to corridors, hotel rooms, museums and general lighting of public spaces. The Nichia LEDs in the PINARA are very efficient and have a high CRI (90). The unique lens that is used in this fixture creates very sharp beams that minimize the spill of uncontrolled light from the fixture. This reduces the glare of the fixture and gives more control to the architects and designers.

PRODUCT LIST & DOWNLOAD

  • Compare
    392001
    • Product Name
      PINARA 1 - Clear or frosted tempered Glass
    • Power - Current
      10W - 350 mA
    • Color
      3000 K
    • Lumen
      1050 lm
    • IP
      IP20
    • LED
      350-500-700 mA
  • Compare
    392002
    • Product Name
      PINARA 1 - Clear or frosted tempered Glass
    • Power - Current
      15W - 500 mA
    • Color
      3000 K
    • Lumen
      1500 lm
    • IP
      IP20
    • LED
      350-500-700 mA
  • Compare
    392003
    • Product Name
      PINARA 1 - Clear or frosted tempered Glass
    • Power - Current
      21W - 700 mA
    • Color
      3000 K
    • Lumen
      2050 lm
    • IP
      IP20
    • LED
      350-500-700 mA
  • Compare
    392011
    • Product Name
      PINARA 1 - Clear or frosted tempered Glass
    • Power - Current
      10W - 350 mA
    • Color
      4000 K
    • Lumen
      1150 lm
    • IP
      IP20
    • LED
      350-500-700 mA
  • Compare
    392012
    • Product Name
      PINARA 1 - Clear or frosted tempered Glass
    • Power - Current
      15W - 500 mA
    • Color
      4000 K
    • Lumen
      1600 lm
    • IP
      IP20
    • LED
      350-500-700 mA
  • Compare
    392013
    • Product Name
      PINARA 1 - Clear or frosted tempered Glass
    • Power - Current
      21W - 700 mA
    • Color
      4000 K
    • Lumen
      2200 lm
    • IP
      IP20
    • LED
      350-500-700 mA
