PINARA Asymetrical - Trimless

  • Technical Specifications
  • Body
    Polycarbonate
  • Diffusers
    With clear or frosted tempered glass, without glass
  • Gear
    Non-Dimmable electronic LED driver (1-10V Dimmable and DALI drivers available on request)
  • Cable
    0.5 m 2 x 0,75 mm H03 VV-F
  • LED
    350 - 500 - 700 mA (Nichia)
  • Heatsing
    Aluminium extrusion profile
  • Springs
    Steel
The PINARA LED downlight is specially designed to deliver high output LED light with very clean beam angles to corridors, hotel rooms, museums and general lighting of public spaces. The Nichia LEDs in the PINARA are very efficient and have a high CRI (90). The unique lens that is used in this fixture creates very sharp beams that minimize the spill of uncontrolled light from the fixture. This reduces the glare of the fixture and gives more control to the architects and designers.

PRODUCT LIST & DOWNLOAD

  • Compare
    392161
    • Product Name
      PINARA Trimless - Asymmetrical
    • Power - Current
      10W - 350 mA
    • Color
      3000 K
    • IP
      IP20
    • LED
      350 - 500 - 700 mA (Nichia)
  • Compare
    392162
    • Product Name
      PINARA Trimless - Asymmetrical
    • Power - Current
      15W - 500 mA
    • Color
      3000 K
    • IP
      IP20
    • LED
      350 - 500 - 700 mA (Nichia)
  • Compare
    392163
    • Product Name
      PINARA Trimless - Asymmetrical
    • Power - Current
      21W - 700 mA
    • Color
      3000 K
    • IP
      IP20
    • LED
      350 - 500 - 700 mA (Nichia)
  • Compare
    392171
    • Product Name
      PINARA Trimless - Asymmetrical
    • Power - Current
      10W - 350 mA
    • Color
      4000 K
    • IP
      IP20
    • LED
      350 - 500 - 700 mA (Nichia)
  • Compare
    392172
    • Product Name
      PINARA Trimless - Asymmetrical
    • Power - Current
      15W - 500 mA
    • Color
      4000 K
    • IP
      IP20
    • LED
      350 - 500 - 700 mA (Nichia)
  • Compare
    392173
    • Product Name
      PINARA Trimless - Asymmetrical
    • Power - Current
      21W - 700 mA
    • Color
      4000 K
    • IP
      IP20
    • LED
      350 - 500 - 700 mA (Nichia)
