ATLANTIS 1 (II)

  • Technical Specifications
  • Body
    316L Stainless Steel
  • Gaskets
    Silicone
  • Diffusers
    Tempered Glass
  • Screws
    Stainless Steel
  • Mounting Brackets
    316L Stainless Steel
  • Recessing Tube
    Aluminium
The Atlantis Near Water series is specially designed to light objects around pools, fountains, and water features or near the sea with high power LED light. The series is made of solid 316L stainless steel and can therefore withstand these rough environments. Standard finish is polished stainless steel to avoid collection of dirt and algae, but a brushed finish is also possible. The series comes as recessed, surface mount or spots. The spots are heavy duty with stainless steel brackets for sturdy fixing. A specially developed power cable ensures for a long lifetime in extreme conditions without any ingress of water. The low voltage electronic LED driver is housed in the base of the fixture. The LEDs used come in 3 different tones of white, as well as blue, red, green, amber or RGB. Several lenses from 6 to 40 degrees are available to choose from to achieve the desired the light effect.

PRODUCT LIST & DOWNLOAD

  • Compare
    412221
    • Product Name
      ATLANTIS 1
    • Power - Current
      1W LED
    • Color
      3000 K
    • Lens
      10°, 25°, 40°
    • Lumen
      85 lm
    • Voltage
      12V AC or DC (24V AC or DC on request)
    • Cable
      Potted 5m 2x0,75 H03 VV-F
    • IP
      IP67
  • Compare
    412226
    • Product Name
      ATLANTIS 1
    • Power - Current
      1W LED
    • Color
      4500 K
    • Lens
      10°, 25°, 40°
    • Lumen
      85 lm
    • Voltage
      12V AC or DC (24V AC or DC on request)
    • Cable
      Potted 5m 2x0,75 H03 VV-F
    • IP
      IP67
  • Compare
    412227
    • Product Name
      ATLANTIS 1
    • Power - Current
      1W LED
    • Color
      6000 K
    • Lens
      10°, 25°, 40°
    • Lumen
      102 lm
    • Voltage
      12V AC or DC (24V AC or DC on request)
    • Cable
      Potted 5m 2x0,75 H03 VV-F
    • IP
      IP67
  • Compare
    421241
    • Product Name
      ATLANTIS 1
    • Power - Current
      3W LED
    • Color
      3000 K
    • Lens
      10°, 25°, 40°
    • Lumen
      225 lm
    • Voltage
      12V AC or DC (24V AC or DC on request)
    • Cable
      Potted 5m 2x0,75 H03 VV-F
    • IP
      IP67
  • Compare
    421242
    • Product Name
      ATLANTIS 1
    • Power - Current
      3W LED
    • Color
      4500 K
    • Lens
      10°, 25°, 40°
    • Lumen
      225 lm
    • Voltage
      12V AC or DC (24V AC or DC on request)
    • Cable
      Potted 5m 2x0,75 H03 VV-F
    • IP
      IP67
  • Compare
    421243
    • Product Name
      ATLANTIS 1
    • Power - Current
      3W LED
    • Color
      6000 K
    • Lens
      10°, 25°, 40°
    • Lumen
      270 lm
    • Voltage
      12V AC or DC (24V AC or DC on request)
    • Cable
      Potted 5m 2x0,75 H03 VV-F
    • IP
      IP67
